Stainless Steel Nozzle Ring Pelton Hydro Turbine with Dual Nozzles for High Head 100m-800m Applications
Подробная информация о продукте:
| Фирменное наименование: | Wawushan |
| Сертификация: | ISO9001 |
| Номер модели: | CJA-202508 |
Оплата и доставка Условия:
| Minimum Order Quantity: | 1 |
|---|---|
| Цена: | 50000 |
| Упаковывая детали: | Стандартный |
| Delivery Time: | 6 Months |
| Payment Terms: | L/C |
| Supply Ability: | 100 Set Per Unit |
|
Подробная информация |
|||
| Номинальная скорость: | 750r/min | Дизайн ковша: | Двойная чашка или разделенное ведро |
|---|---|---|---|
| напор воды: | 100-800 метров | Кольцо для насадки: | Нержавеющая сталь 0Cr13Ni4Mo (CA6NM) |
| Тип: | Импульсная турбина | Тип бегуна: | Одиночный или Мульти-двигатель |
| голова дизайна: | 200м-600м | Название продукта: | Турбина Pelton гидро |
| Выделить: | Stainless Steel Nozzle Ring Pelton Hydro Turbine,Dual Nozzles Water Impulse Turbine,High Head 100m-800m Hydro Jet Turbine |
||
Характер продукции
Pelton Hydro Turbine - High-Efficiency Power Generation
The Pelton Hydro Turbine is a state-of-the-art reaction hydro turbine engineered for exceptional performance in high-pressure water head applications. Designed for efficiency and durability, this high-efficiency turbine harnesses energy from water heads ranging from 50 to 1000 meters, with optimal operation between 100 and 800 meters.
Featuring a premium stainless steel 0Cr13Ni4Mo (CA6NM) nozzle ring, this turbine delivers superior strength and exceptional corrosion resistance, ensuring reliable operation in harsh environments and high-pressure conditions.
Key Features
- Impulse Turbine Type with Dual Nozzle Configuration
- Design Head Range: 200m-600m
- Double Cup or Split Bucket Design
- High Strength and Anti-Corrosion Construction
- Optimized for Various Hydro Power Applications
- Water Jet Turbine Technology for Maximum Energy Conversion
Technical Specifications
| Product Name | Pelton Hydro Turbine |
| Type | Impulse Turbine |
| Power Capacity | 1-200 MW |
| Nozzle Number | Dual Nozzles |
| Nozzle Ring Material | Stainless Steel 0Cr13Ni4Mo (CA6NM) |
| Runner Type | Single or Multi-Jet |
| Bucket Design | Double Cup or Split Bucket |
| Efficiency | Up to 90% or Higher |
| Rated Speed | 750r/min |
Applications
The Wawushan CJA-2025 Pelton Hydro Turbine is engineered for high-head hydroelectric power generation in mountainous regions and hilly terrain. Ideal for small to medium-sized hydroelectric plants, industrial power generation, and remote off-grid power solutions.
Model Specifications
Model: CJA-2025
Certification: ISO9001
Flow Rate: 1-200 M³/s
Noise Level: Low Operation
Customization Options
Wawushan offers customizable Pelton Hydro Turbine solutions tailored to your specific project requirements. With a minimum order quantity of 1 set and supply capacity of 100 sets per unit time, we provide flexible solutions for diverse hydroelectric applications.
Pricing & Delivery
Price: $50,000 per unit
Delivery Time: 6 months
Payment Terms: L/C
Technical Support & Services
Our comprehensive support includes expert guidance on installation, operation, and maintenance. We provide detailed documentation, training sessions, on-site inspections, and preventive maintenance to ensure optimal performance and longevity of your turbine investment.
Хотите узнать больше подробностей об этом продукте
